Actuator for 8 rolling shutters KNX - 01525

01525
Smart systems&products / KNX / Shared components / DIN devices

Actuator for 8 rolling shutters KNX
Actuator for 8 roller shutters, 6 A 230V~ 50/60 Hz relay outputs, KNX standard, installation on DIN rail (60715 TH35), occupies 8 17,5 mm modules

Product Status
2 - Will be discontinued

Alternative products

01532 - KNX Secure actuator 16 OUTS 250V 10AX

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (1047 kb)
• Manuale installatore (1110 kb)
• Installer manual (2706 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Shutting actuator for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Radio frequent bidirectional
No

Mounting method
Other

Width in number of modular spacings
8

With bus connection
Yes

Bus module detachable
No

Local operation/hand operation
No

With LED indication
No

Number of inputs
0

Switching current (resistive)
6 A

Max. number of venetian-blind outputs
8

With switch function
Yes

Type of current
AC

Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352517912

1 NR

15x9.2x6.6 [cm]

418 [g]

8007352738843

11 NR

40x37x8 [cm]

4,598 [g]
