KNX 2 roller blinds actuator - 01524

01524
Smart systems&products / KNX / Shared components / DIN devices

KNX 2 roller blinds actuator
Actuator for 2 roller shutters, cosφ 0.6 3,5 A 250 V~ motor relay outputs, KNX standard, installation on DIN rail (60715 TH35), occupies 4 17,5 mm modules

Product Status
2 - Will be discontinued

Alternative products

01523.1 - 250V 16A 4-output actuator KNX

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (543 kb)
• Manuale installatore (695 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Shutting actuator for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Radio frequent bidirectional
No

Mounting method
Other

Width in number of modular spacings
4

With bus connection
Yes

Bus module detachable
No

Local operation/hand operation
Yes

With LED indication
Yes

Number of inputs
0

Switching current (resistive)
16 A

Max. number of venetian-blind outputs
2

With switch function
Yes

Type of current
AC

Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352383593

1 NR

11.7x10.8x7.1 [cm]

254.1 [g]
