12-output 250V 10AX KNX actuator - 01521.1

01521.1
Smart systems&products / KNX / Shared components / DIN devices

12-output 250V 10AX KNX actuator
Actuator with 12 10 A 250 V~ 50/60 Hz relay outputs for fluorescent lamps, KNX standard, installation on DIN rail (60715 TH35), occupies 12 17,5 mm modules

Product Status
2 - Will be discontinued

Alternative products

01532 - KNX Secure actuator 16 OUTS 250V 10AX

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (389 kb)
• Installer manual (2971 kb)
• Manuale installatore (3332 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Actuating drive for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Radio frequent bidirectional
No

Mounting method
Other

With bus connection
Yes

Temperature control with built-in continuous control
No

Buttons for manual operation at the drive
Yes

Function master/slave
No

Nominal voltage
250 V

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352605985

1 NR

23.1x11x8.5 [cm]

698.6 [g]
