Binary input 4-channel 120/230V KNX - 01510

01510
Smart systems&products / KNX / Shared components / DIN devices

Binary input 4-channel 120/230V KNX
4-channel digital input device, programmable for NO, NC and 120-230 V~ contacts, KNX standard, installation on DIN rail (60715 TH35), occupies 2 17,5 mm modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (619 kb)
• Manuale installatore (659 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
I/O device for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Width in number of modular spacings
2

With bus connection
Yes

LED controlling
No

With LED indication
Yes

Local operation/hand operation
Yes

Suitable for C-load
Yes

With switch function
No

External signal voltage necessary
No

Different phases connectable
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352383555

1 NR

14.2x6.7x5.9 [cm]

109 [g]
