Device 4 buttons+dimmer 0/1-10V 2M - 01489

Pdf
Vimar - 01489 - Device 4 buttons+dimmer 0/1-10V 2M
Vimar - 01489 - Device 4 buttons+dimmer 0/1-10V 2M

01489
Smart systems&products / By-me Plus / Shared components / Devices

Device 4 buttons+dimmer 0/1-10V 2M
4-button device for By-me Plus smart automation, 1 0/1-10 V SELV output, 1 NO 2 A 120-240 V~ 50/60 Hz relay output for ballast and LED driver, visible in darkness with RGB LED brightness adjustment, to be completed with Eikon, Arké and Plana series 1-or 2-module interchangeable half-buttons - 2 modules

Product Status
3 - Active

Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
No
Bus system LON
No
Bus system Powernet
No
Radio frequency bidirectional
No
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With integrated DCF77 receiver
No
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Other
RAL-number (similar)
7024
Transparent
No
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352614055
1 NR
6x5.4x5.3 [cm]
72.5 [g]
Barcode Qty 10 NR
8007352614062
10 NR
28.1x13.1x6 [cm]
804.2 [g]
